HS336-ADA-MS / HS348-ADA-MS Full Height Steel Gate with Security Mesh

Description Our Full Height ADA Gate with Mesh is engineered to meet the most demanding security and control requirements. Paired with our HS400 series full-height turnstiles, they provide ADA accommodation to any project. Crafted from tubular steel or meshed with a push bar for free-exit projects, the HS336 completes any access control job. These units are available in your choice of galvanized or powder-coated carbon steel or stainless steel (304 or 316 for extra corrosion resistance) finishes, matching your turnstile array. Data Sheet – HS336 / HS348 ADA Gate Installation Manual – HS336 / HS348 ADA Gate Hot-Dip Galvanizing – Data Sheet *Required Form: Please email with your Order: Production Sheet – ADA Swing Gate   FEATURES Standard Hardware Mesh: Security Steel Mesh Weave prevents any breach Door Closer: Locinox Mammoth 180 or Norton 9300 Series Deadlock: Adams Rite 4510 Series with 31/32″ backset Strike: Adams Rite 7100 Series electronic strike – 24VDC Cylinder: Mortise Cylinder APPLICATION/USE Interior OR Exterior Use HS336-ADA Model: Self-closing heavy duty swing gate provides wheelchair accessible 36” passage (with an overall width of 43.375”) HS348-ADA Model: Self-closing heavy duty swing gate provides wheelchair accessible 48” passage (with an overall width of 55.375”) Reversible electronic strike can be set to lock or open on power failure Gate can also be unlocked with no power by configuring the strike to fail lock by using a key Gate automatically swings closed with a standard hydraulic door closer Voltage for the electronic strike can be taken from a nearby turnstile power supply When the HS400 Series Full Height Security turnstile is “Free Exit”, the HS336-ADA & HS348-ADA swing gate should also be free exit OPTIONS FOR THE HS336-ADA & HS348-ADA Panic Hardware – Latch Paddle – Adds a latch paddle to the exit side of the gate for free passage (mesh models only) Panic Bar Hardware – Full Panic Bar – Adds a panic bar to the exit side of the gate for free passage (mesh models only) Panic Bar Upgrade – Signal Monitoring Switch – Adds a SPDT switch to mirror panic bar status with wire transfer kit to feed wires from door to frame Panic Bar Upgrade – Battery Powered Alarm – Local alarm sounds when pushbar is pressed Panic Bar Barrier (Reach Through Barrier) – Prevents reaching gate’s push bar from the outside. In choice of finish. Motorized Door Opener – Adds 3” to overall height of door Magnetic Lock – Can replace the strike lock if requested Card Reader Mounting Plate/Enclosure (1 per electronic direction) – For mounting most standard card readers Request to Exit ADA Placard Button with Plastic Surface Mount Enclosure – Rectangular or round Single Push Button (installed on-site) One Channel 900 MHz Wireless Receiver (one per direction) – Must be mounted remotely Wireless Key Fob Transmitter (1 button) 24 Volt Power Supply (if being used electronically and not purchased with a turnstile) Custom Passage Widths – Call for quote Powder Coating Over Galvanizing Upgrade – Weatherizes gate for outdoor use 316 Stainless Steel Upgrade – Standard is 304 Stainless Need 2-way Access Control (no panic bar?) See HS336-ADA-VB with Vertical Steel Bars   FINISH CHOICES Carbon Steel – Galvanized (GALV) Carbon Steel – Powder Coated (PC) **Indoor installations Carbon Steel – Powder Coated over Galvanized (POG) **Select this if Outdoors! Increased weatherization from POG. Stainless Steel/Satin Finish (304): Ideal for food service, manufacturing, hospitality, anywhere that aesthetics are important Stainless Steel/Satin Finish (316): Ideal for coastal areas, marine applications, areas exposed to corrosive chemicals and/or chloride (de-icing salts) DRAWINGS & DIMENSIONS HS336-ADA-MS – Dimension Drawing HS336-ADA-MS – ABCD Anchor, Base, Conduit Detail HS348-ADA-MS – Dimension Drawing HS348-ADA-MS – ABCD Anchor, Base, Conduit Detail INSTALLATION PHOTOS Above: Custom colors gloss red and black, HS336-ADA Gate with Mesh with Single Turnstile. See More Photos > Above: Galvanized HS336-ADA Gate with Mesh, Single Turnstile, and Filler Barrier. See More Photos > Above: Tandem Turnstile, two HS336-ADA Gates with Mesh, and Matching Climbover Filler Barriers to fill the space above the turnstile and gate to the ceiling. Above: Tandem Turnstiles, HS348-ADA Gate with Mesh, Galvanized. See More Photos > Above: HS448-Single Turnstile, HS348-ADA Gate with Mesh, Stainless Steel. See More Photos >
